Description
AG176B on standard trailer with hose reel (mounted) and Force 5 blowgun included
The Brüder AG176 is by far our most popular compressor for blowing down headers, balers, bins and other harvest equipment to reduce fire risk and remove built-up debris.
Brüder Kompressor has been developed in response to the growing need for a dependable, tough and practical machine for use in Australia’s harsh agricultural environment.
Compact yet powerful, the standard size AG176 Kubota-driven rotary screw compressor pumps out 176 cubic feet per minute – the ideal flow rate for effective cleaning and machinery blowdown. With a unique cooling system and filters designed for hot and dusty conditions, the Bruder AG176 thrives in high ambient temperatures, ensuring reliability during long, hot days in the field.
- Free Air Delivery: 176cfm (5m3/min)
- Working Pressure: 7 bar (101 PSI)
- Engine: Kubota V1505-T Turbo Diesel
- Engine Rated Power at 3000RPM: 36.4 HP (27 kW)
Brüder AG176 on Basic Farm Trailer (unbraked) with optional mounted hose reel and Force 5 Megablaster blow gun.
Superior harvest compressor features
- Single piece steel canopy – for easy access to all service parts
- Vertical top exit exhaust – reduces fire risk when standing in dry crop
- Extra long drawbar*, heavy duty jockey wheel – easier to manoeuvre
- Unique airflow design and firewall – provides optimal cooling in high ambient temperatures
- Side mounted valves and outlets – for operator safety and ease of access
- Kubota turbo diesel – lightweight, compact, reliable, and powerful with established service network
- IntelliDrive Nano – user friendly digital control system to protect and regulate compressor
- 70 litre poly fuel tank – longer running hours, visible fuel level
- Heavy duty trailer, specifically designed for harsh environments with features like off-road springs*, welded steel wheel arches, high ground clearance, and brakes*
- Large steel wheels with all-terrain tyres and a spare included as standard*
- Spin-on filters – easy servicing and replacement
*Deluxe trailer only, see below comparison on trailers
AG176 on Deluxe trailer with canopy open
Technical parameters
| Compressor | AG176 (7 bar) | AG176 (10 bar) | |
| Air end | B100 | B100 | |
| Nominal capacity | [m3/min] | 5 | 3.8 |
| Nominal overpressure | [bar] | 7 | 10 |
| Safety valve setting | [bar] | 10 | 12.5 |
| Ambient temperature | [˚C] | -10 to +50 | -10 to +50 |
| Max outlet temperature | [˚C] | 110 | 110 |
| Cooling system | Oil injection | Oil injection | |
| Compressor oil filling volume | [Litres] | 7.2 | 7.2 |
| Max oil system temperature | [˚C] | 110 | 110 |
| Max oil system pressure | [bar] | 8.6 | 11.6 |
| Outlet valves | 2 x G3/4″ BSP | 2 x G3/4″ BSP | |
| Engine | |||
| Type/Model | Kubota 1505-T | ||
| Cylinders | 4 | ||
| Load speed | [rpm] | 3000 | |
| Idle speed | [rpm] | 1500 ± 50 | |
| Oil filling volume | [Litres] | 6.7 | |
| Fuel tank volume | [Litres] | 70 | |
| Coolant filling volume | [Litres] | 4 | |
| Battery | [V/Ah] | 12/44 |
| Noise emissions | ||
| Sound power level LWA | [dB(A)/pW] | 98 |
| Sound pressure level LPA | [dB(A)/20 𝜇Pa] | 78 |
